| Place of Origin: | CHINA |
|---|---|
| Certification: | CE ,ISO |
| Model Number: | LNWL-2055-2 |
| Minimum Order Quantity: | one set |
| Packaging Details: | Nude packing&fixed by iron wire |
| Delivery Time: | 30 work days |
| Payment Terms: | L/C,T/T |
| Supply Ability: | 10 sets/month |
| Mesh Size: | 55x70mm | Mesh Wdith: | 2200mm |
|---|---|---|---|
| Max Wire Dia: | 1.2mm | Machine Motor: | 3kw |
| Name: | Hexagonal Wire Netting Machine | Theoretic Output: | 162m/hr |
| High Light: | wire net making machine,automatic chain link fence machine |
||
Automatic Spring Coiling Machine , Hexagonal Wire Netting Machine With High Efficiency
Quick Detail:
1) Mesh sizes: 55x70mm
2) Max netting width: 2200mm
3) Max galvanized wire diameter: 1.2mm
4) Power: 3kW
5) Theoretic output: 162m/hr
Machine Descrition:
1. professional manufacturer, not trading company, we supply advanced
machine to oversea clients directly only. We can produce the machine as your requirement.
2.Model GLL (T) is a light series of mesh weaving machines, including 7 different types of
machines, i.e. with which the galvanized hexagonal wire mesh of different apertures can be
woven
3.The maximum diameter of the wire that can be woven on this type of machine is 1.2m. This
series of product include two types of machines, i.e. the single-head and the double-head
machine
4.The maximum weaving breadth of the single-head machine is 1.2m and that of the double-
head machine is 2.2m
5.Separated from the middle, the double-head machine can weave two 1m wide meshes
simultaneously
6.Type 1/2' and Type 3/4' machine can weave trapezoidal wire-mesh after necessary refitting
7.This kind of wire-mesh is widely used as the skeleton of the asbestos shingle
Machine Specifications:
| Style | Specification | Mesh size | Width | Wire diamater |
Twisting Lines |
Spindle Speed | power of motor |
Theoretic output |
| (mm) | (mm) | (mm) | r | (r/min) | (kw) | (m/h) | ||
| LNWL-1015-2 | 1/2' | 15x18 | 1200 | 0.8 | 3 | 33 | 3 | 51 |
| LNWL-1018-2 | 5/8' | 18x5 | 0.9 | 3 | 67 | |||
| LNWL-1022-2 | 3/4' | 22x33 | 1.2 | 3/5 | 83 | |||
| LNWL-1027-2 | 1' | 27x41 | 3/5 | 100 | ||||
| LNWL-1032-2 | 1/1/4' | 32x52 | 3/5 | 122 | ||||
| LNWL-1039-2 | 1/1/2' | 39x61 | 3 | 142 | ||||
| LNWL-1055-2 | 2' | 55x70 | 3 | 162 | ||||
| LNWL-1078-2 | 3' | 78x86 | 3/5 | 194 | ||||
| LNWL-2015-2 | 1/2' | 15x18 | 2200 | 0.8 | 3 | 33 | 3 | 51 |
| LNWL-2018-2 | 5/8' | 18x5 | 0.9 | 3 | 67 | |||
| LNWL-2022-2 | 3/4' | 22x33 | 1.2 | 3/5 | 83 | |||
| LNWL-2027-2 | 1' | 27x41 | 3/5 | 100 | ||||
| LNWL-2032-2 | 1/1/4' | 32x52 | 3/5 | 122 | ||||
| LNWL-2039-2 | 1/1/2' | 39x61 | 3 | 142 | ||||
| LNWL-2055-2 | 2' | 55x70 | 3 | 162 | ||||
| LNWL-2078-2 | 3' | 78x86 | 3/5 | 194 |
Competitive Advantage:
1. Our company invented the first special equipment of double twisted wire netting
making machine in China (patent number: ZL99229381.2 and ZL00267066.5). And until now,
we have persevered in this area of gabion machine making for 15 years.
2. All the parts of gabion machine are processed by our own factory; no parts were sending to
outside to process, so the quality can be ensured.
3. We can provide 12months guarantee for all the equipments, and if customer need, we will
arrange our technician to help install the machines in your country, and also could supply all
the spare parts with cost price if customer need.
