Galvanized Chain Link Fence Machine / Fencing Wire Manufacturing Machine With 4000 mm Width

Basic Information
Place of Origin: CHINA
Certification: ISO,CE
Model Number: CLM-60
Minimum Order Quantity: One set
Packaging Details: Nude Packing&Fixed by iron wire
Delivery Time: 30 work days
Payment Terms: L/C,T/T
Supply Ability: 10 sets/month
Mesh Size: 25-80mm Machine Width: 4000mm
Wire Diameter: 2.0-4.0mm Motor Power: 5.5 KW
Name: PLC Automatic Chain Link Fence Machine Application: Residence
High Light:

automatic chain link machine

,

diamond mesh wire making machine

Galvanized Wire Chain Link Fence Machine , PLC Automatic Chain Link Fence Machine



Description:


1 The chain link is automatically wound to form rolls when the desired length is manufactured.
2. The machine is controlled by PLC automatic controller, so only one person is needed to operate it.
3 One side or both sides of the end of net hole is twisted or with burr in edge.

4. Use compacting machine to make it into rolls.





Technical parameter



Max. weaving width 4m
Max weaving length as customers request
Mesh opening 25-80mm
Wire diameter 2-4mm
Raw material Galvanized wire, PVC Coated wire, etc.
Servo Motor 5.5 KW
Motor for side dealing 1.5 KW
Motor for parting tool 1.5 KW
Motor for winding 0.75 KW






Machine advantage



1.  motor and gear box, rate 1:3
2. Single mold, double spiral, so have high production
3. PLC control and touch screen
4. hanging control panel
5. Weaving the side
6. Roll the mesh automatically
7. Alarm device and emergency Button

8. The raw material can be galvanized wire, pvc

8. We accept any special orders from clients.

Galvanized Chain Link Fence Machine / Fencing Wire Manufacturing Machine With 4000 mm Width 0
