Fully Automatic Wire Coiling Machine , 100x120mm Gabion Mesh Machine PLC Control Simple Install

Basic Information
Place of Origin: China
Certification: ISO,CE
Model Number: LNWL43-100-3
Minimum Order Quantity: one set
Packaging Details: Nude packing and fixed by iron wire
Delivery Time: 30 work days
Supply Ability: 10 sets/month
Material: GI Wire&PVC Coated Wire Wire Diameter: 1.6-4.0mm
Motor Power: 22kw Machine Speed: 195m/h
Name: Gabion Mesh Making Machine Control: PLC Automatic
High Light:

gabion wire mesh machine


gabion making machine

Fully Automatic Wire Coiling Machine , 100x120mm Gabion Wire Mesh Machine PLC Control



 Gabion mesh machine  details


1. Gabion Mesh Machine is the professional machine to produce inerratic gabion mesh, the mesh can be


to produce coop, and is widely used as protect and sustain bank, hillside, road and bridge, reservoir and

other construction project.

2. it is the good material to prevent or control flood.





Mesh Size(mm) Max. Width(mm) Wire diameter(mm) Twisting Number Main Drive Shaft Speed(r/min) Motor Capacity(KW) Theoretical Speed(m/h)
LNWL23-60-2 60*80 2300 1.6-3.0 3 25 11 165
LNWL23-80-2 80*100 1.6-3.0 195
LNWL23-100-2 100*120 1.6-3.5 225
LNWL23-1200-2 120*150 1.6-3.2 20 255
LNWL43-120-3 120*150 4300 1.6-3.2 5 20 2 255




Preventing of rock breaking;
Water and soil protection;
Bridge protection;
Strengthening structure of soil;
Protection engineering of seaside area




1. Simple to install – Using unskilled labour.

2. Environmentally acceptable-The use of local rock and soils for backfill is encouraged, with the subsequent growth of vegetative cover made easy

3. Flexible Nature – Able to move and settle without failure, even on unstable soils.

4. The gabion wire mesh is folding and can be assembled site,which saves on transport cost


Fully Automatic Wire Coiling Machine , 100x120mm Gabion Mesh Machine PLC Control Simple Install 0
