Energy Saving Gabion Machine LNWL33-120-2 With Air Compressor Wire Tensile System

Basic Information
Place of Origin: China
Certification: ISO,CE
Model Number: LNWL33-120-2
Minimum Order Quantity: one set
Packaging Details: Nude packing and fixed by iron wire
Delivery Time: 30 work days
Supply Ability: 10 sets/month
Product Name: Stone Cage Wire Mesh Machine Mesh Size: 120X150
Width: 3300mm Wire Diamater: 1.6-3.5mm
Spindle Speed: 20r/min Application: Protection Engineering Of Seaside Area
High Light:

hexagonal wire mesh machine


gabion wire mesh machine

Energy Saving Gabion Mesh Machine Air Compressure Wire Tensile System Included





Gabion machine consists of rectangular units, fabricated from a double twisted hexagonal mesh. Filled with stones, gabions become large, flexible and permeable elements from which a broad range of structures may be built.
Gabion box are divided into cells with diaphragms (usually spaced at 1 meter or 3’intervals), whose function is to reinforce the structure. The mesh (except for the diaphragms) is reinforced on all edges with wires of a larger diameter to strengthen the gabions




Gabion Machine widely used in oil, construction, raising, chemical industry warming piping and etc. It is also used in fence, apartment and greening. The hexagonal wire netting can be used in protect sea wall, hillside, road, bridge and civil engineering. It is one of the best against flooding material.



Machine Specifications:


Style Mesh size Width Wire diamater Spindle Speed power of motor Theoretic output
(mm) (mm) (mm) (r/min) (kw) (m/h)
LNWL33-120-2 120X150 3300 1.6-3.5 20 15 255



  Machine Advantages:


1. Simple to install – Using unskilled labour.
2. Environmentally acceptable-The use of local rock and soils for backfill is encouraged, with the subsequent growth of vegetative cover made easy
3. Flexible Nature – Able to move and settle without failure, even on unstable soils.



Why always choose SUNRICH?


+ The earliest manufacturer of Gabion machine in China.

+ We have experience of export business for more than 10 years.

+ The finished products can meet international standard ASTM , BS, EN and pass ISO,SGS quality certificate system.

+ Complete material testing system and QC system.

+ Experienced staffs, the fastest delivery time.

+ Best service (Any enquiry will be replied within 24 hours). Thanks for your reading!
