Gabion Machine
Created with Pixso. 3 Twisting Lines Gabion Machine 95m/H Speed For Protect Sea Wall ISO Approved
3 Twisting Lines Gabion Machine 95m/H Speed For Protect Sea Wall ISO Approved
  • name
  • name

3 Twisting Lines Gabion Machine 95m/H Speed For Protect Sea Wall ISO Approved

Model Number: LNWL43-80-2
MOQ: one set
Delivery Time: 30 work days
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
ISO,CE
Mesh Size:
100mmx120mm
Wire Diameter:
3.7mm
Twisting Lines:
3
Speed:
95m/h
Name:
Gabion Wire Mesh Machine
Application:
Protect Sea Wall
Packaging Details:
Nude packing and fixed by iron wire
Supply Ability:
10 sets/month
Highlight:

hexagonal wire mesh machine

,

gabion wire mesh machine

Product Description



Raising 3 Twisting Lines Heavily Galvanized Gabion Mesh Machine with High Efficiency



Quick Detail:

  1. Style :LNWL33-100-2
  2. Mesh size(mm) :100x120
  3. Width(mm):3300
  4. Speed(r/min): 225
  5.   PLC control system touch screen(Option)
  6. ​Infrared ray safety(Option)
  7. Automatic stop system (Option)
  8. Automatic oil system



The Gabion machhine of Application



  1. produce coop
  2. sustain bank
  3. hillside
  4. road and bridge
  5. reservoir





Specifications:



Gabion mesh  Machine Specification
Style Mesh size Width Wire diameter Twisting Lines Speed Power of Motor
(mm) (mm) (mm) r (r/min) (kw)
LNWL33-60-2 60x80 3300 2.7 3 165 22
LNWL33-80-2 80x100 3.0 3 195
LNWL33-100-2 100x120 3.7 3 225
LNWL33-120-2 120x150 4.0 3 255






Gabion Machine Advantages:


1. The type machine you can choose two racks to make the machine operating more stable.



2. The equipment's framework is more reasonable, design is innovation, function is more perfect and safe using, the important is that weavng mesh is more easier than before.



3. The equipment can add automatic stop system, that means when there is no wire machine can stop sutomatically.



4. You can add Infrared ray safety function, it can stop automatically when worker touch the infrared. It can prevent worker injury.
