| Place of Origin: | China |
|---|---|
| Certification: | ISO,CE |
| Model Number: | LNWL57-100-2 |
| Minimum Order Quantity: | One set |
| Packaging Details: | Nude packing& fixed by iron wire |
| Delivery Time: | 30 work days |
| Twist: | Double Twist | Max. Netting Width: | 2300mm |
|---|---|---|---|
| Max. Galvanized Wire Diameter: | 3.5mm | Material: | Steel Welding |
| Control: | Automatic Stop And Counter | Name: | Gabion Mesh Machine |
| High Light: | wire mesh welding machine,gabion wire mesh machine |
||
Stone Cages Wire Mesh Knitting Machines , Double Twist Hexagonal Mesh Machine
Description
Gabion mesh machine is the professional machine to produce gabion mesh box, which is wildly used in protecting and sustaining bank, hillside, road and bridge, reservoir and other construction project, and it is the good material to prevent or control flood
Application
1. Gabion Mesh machine is also called Heavy-duty hexagonal wire netting machine.
2. The gabion box is made of pieces of hexagonal wire netting,which is mainly uesd as building material
3. it can be used in resevior for closure,and also seaves as highway guard rail netting,railway guard rail netting,green guard rail netting,side hill mesh case,flood fighting mesh case,dike dam guard rail netting,zoo guard rail netting
Specification:
| Style | Mesh size | Width | Wire diamater | Spindle Speed | power of motor | Theoretic output |
| (mm) | (mm) | (mm) | (r/min) | (kw) | (m/h) | |
| LNWL43-60-3ZX | 60X80 | 4300 | 1.6-3.2 | 25 | 22 | 165 |
| LNWL43-80-3ZX | 80X100 | 1.6-4.0 | 195 | |||
| LNWL43-100-3ZX | 100X120 | 225 | ||||
| LNWL43-120-3ZX | 120X150 | 1.6-4.0 | 20 | 255 |
Advantages:
1. CE / TUV certificate.
2. QC system & timely delivery.
3. New drive mode.
4. Automatic oil system.
5. Overload protect clutch.
6. High-efficiency: theoretic output = 3.5m/min.
7. Turbine protection system (Option).
8. Infrared ray safety (Option).
9. Automatic stop system (Option).
10. All of the core parts of machines are processed by our own factory, so the quality can be ensured.
11. KONSON offer better after-sale service. We can provide 12 months guarantee for all the equipments,
