1200mm Automatic Reverse Twist Hexagonal Wire Netting Machine ,Gabion Wire Mesh Making Machine
Descrition:
Hexagonal Wire Netting Machine is designed to produce hexagonal wire mesh, which suitable for poulary fence, construction project,hillside, road and bridge, heat insulation, protective applications.
It has three types : Normal and reverse twist,Normal twist,Heavy duty hexagonal wire mesh machine (also called gabion wire mesh machine).
Specifications:
| Style | Specification | Mesh size | Width | Wire diamater |
Twisting Lines |
Spindle Speed | power of motor |
Theoretic output |
| (mm) | (mm) | (mm) | r | (r/min) | (kw) | (m/h) | ||
| LNWL-1015-2 | 1/2' | 15x18 | 1200 | 0.8 | 3 | 33 | 3 | 51 |
| LNWL-1018-2 | 5/8' | 18x5 | 0.9 | 3 | 67 | |||
| LNWL-1022-2 | 3/4' | 22x33 | 1.2 | 3/5 | 83 | |||
| LNWL-1027-2 | 1' | 27x41 | 3/5 | 100 | ||||
| LNWL-1032-2 | 1/1/4' | 32x52 | 3/5 | 122 | ||||
| LNWL-1039-2 | 1/1/2' | 39x61 | 3 | 142 | ||||
| LNWL-1055-2 | 2' | 55x70 | 3 | 162 | ||||
| LNWL-1078-2 | 3' | 78x86 | 3/5 | 194 | ||||
Main Product:
|
Competitive Advantage:
1. All the parts of gabion machine are processed by our own factory; no parts were sending to outside to
process, so the quality can be ensured.
2. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our
technician to help install the machines in your country, and also could supply all the spare parts with cost
price if customer need.
Our products are sold all over the world, you can rest assured.
