| Place of Origin: | CHINA |
|---|---|
| Certification: | ISO9001,ISO14000 |
| Model Number: | LNWL-2 |
| Minimum Order Quantity: | 100 sets |
| Packaging Details: | Packing by mesh packing machine&fixed by iron wire |
| Delivery Time: | 15 work days |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 120000 m2/month |
| Wire Diameter: | 2.7mm | Selvedge Wire Dia: | 3.0mm |
|---|---|---|---|
| Box Size: | 2x1x1m | Mesh Size: | 100x120mm |
| Name: | Hexagonal Mesh Gabion Box | Materials: | Low Carbon Hot Dipped |
| High Light: | gabion wall baskets,gabion wall cages |
||
Flood Twisted Gabion Box , Hot Dipped Galvanized Welded Wire Mesh
Quick Detail:
Gabion Box are multiple twisted hexagonally woven galvanized or PVC coated steel wire mesh compartmented baskets with a rectangular box shape. The compartments are of equal dimension and are formed by internal diaphragms. The compartment is filled with natural stone and the diaphragms assure minimum stone migration within the basket. Thus providing even distribution of the stone even in abnormal conditions, and adding strength to the container to help retain its rectangular shape during the filling operation.
Specifications:
|
Material: Low-Carbon Iron Wire,Galvanized Iron Wire Wire Diameter: 3-6 mm,such as 3.5 mm,4 mm,5 mm,6 mm Zinc Coated: 200-300 g/㎡ Surface Treatment: hot dip galvanzed after welded Stiffener length: 300 mm Spiral Binder wire diameter: 3.7 mm etc. Mesh Hole: 5 x 5 cm,5 x 10 cm,7.5 x 7.5 cm,10 x 10 cm,10 x 20 cm Box Size : 2 x 1 x 1 m, 2 x 1 x 0.5 m, 1 x 1 x 1 m, 1 x 1 x 0.5 m, 1 x 0.5 x 0.5 m, 0.3 x 0.3 x 0.3 m, as your request. |
Gabion boxes applications:
